Description

WFRETRO4

Looking to upgrade existing downlights with the contemporary look of low-profile, edge-lit wafers? The WFRETRO quickly installs into most standard housings and can be used in both indoor and outdoor applications. The WFRETRO installs like any standard retrofit downlight. Simply remove the old bulb or trim, screw the Edison base adapter into the socket, and lock in place with torsion springs or friction clips. (Fits most 4″ and 5/6″ cans)

• Edge-lit wafer look that retrofits in existing downlight housings
• Field adjustable: 3 brightness levels & 5 CCTs
• Smooth or step baffle lens
• Mounts inside standard 4″ or 5/6″ recessed downlight housings

Spec Sheets

Family Spec Sheet

Smooth / Baffle

Installation Instructions

Info

Product Type	Flatt Wafer Retrofit
Wattage	10/8/6W
Lumen	835/685/525
Color Temp.	Field Adjustable
CRI	90
L70 Lifespan	50,000
Housing Material	Plastic+Metal
Finish	White Trim
Style	Smooth | Baffle
LED	Long-life, high-efficacy, surface-mount LEDs
Socket Adapter	Edison 26 Medium Base Socket adapter included in box
Beam Angle	110°±10°
Lens	Polycarbonate light diffuser distributes light evenly and smoothly for general lighting applications
Mounting	Easy installation with friction clips (4″) and torsion springs (5″/6″)

Additional Info

Compliance Safety Listing UL Listed Environment/Fixture Rating Wet Location T24 JA8 Compliant Can be used to conform with the requirements of California Title 24 Part 6. IC Rated No Energy Star Compliant Yes Air Tight Yes FCC Complies with Part 15 of the FCC Rules RoHS Mercury and UV free. RoHS-compliant components

Electrical THD ≤20% Power Factor ≥0.9 Input Voltage 120V Operating Frequency 60Hz Operating Temperature -30°C to 40°C Dimming TRIAC and ELV dimming compatibility

Note All values are typical (tolerance +/- 10%)
