Panasonic WhisperFit® DC Fan With Dimmable LED & Nightlight 50-80-110 CFM

WhisperFit® DC Fan / Dimmable LED & Nightlight is an ideal retrofit solution. Built-in energy efficient ECM (DC) motor with Pick-A-Flow™ airflow selector allows you to select required airflow (50, 80 or 110 CFM). Single-hinged Flex-Z Fast® bracket, pre-installed alignment guides, and temporary clip allows for flexible, fast and easy installation. Can be used to comply with the latest codes and standards. Includes a 10 Watt dimmable LED 30K/90CRI/700 lumens/70 LPW/ ENERGY STAR® 2.0 certified/JA-8 compliant for CA Title 24/50,000 hours rated average life / <1W LED night light.

Dimensions Length (In.) 10.25″ Height (In.) 10.25″ Width (In.) 5.625″

• Revolutionary ECM motor with SmartFlow™ Technology ensures optimal CFM output
• Built-in Pick-A-Flow™ airflow selector allows you to select your required airflow of 50, 80, or 110 CFM with a simple flip of a switch
• Lighted model incorporates one 10W dimmable LED chip panel with <1W LED night light for warm, long-life energy efficient illumination (night light must be wired separately)
• Single-hinged Flex-Z Fast® bracket provides flexible, fast and easy installation
• Can be used to comply with ASHRAE 62.2, LEED, IAP and California Title 24
• Includes a 30K 10W LED

Spec Sheets

Spec Sheet

Installation Instructions

Info

CFM	50/80/110
Color	White
Duct Size	4
Grille Length x Width	13″ X 13″
Sound Level (Sones)	1.0-1.3
Warranty	6 year DC Motor, 3 Year Parts

Additional Info

UL Listed for use over bathtubs or showers when connected to a GFCI circuit	Yes
Rated Amps	0.28
Voltage	120V
ENERGY STAR® certified	Yes
Humidity Sensing	No
Motion Sensing	No
Night Light	Yes
