Panasonic FV-0510VSC1 WhisperValue 50/80/100 CFM DC Fan with Condensation Sensor

Description

PRODUCT DESCRIPTION

WhisperValue® DC™ Fan with pre-installed condensation sensor helps control bathroom condensation to prevent mold and mildew. It is the lowest profile ENERGY STAR® rated ventilation fan available. Ideal for residential construction (Single & Multi-Family) and Manufactured Homes. It features Panasonic’s revolutionary ECM motor with SmartFlow™ optimum CFM technology, and incorporates a Pick-A-Flow™ speed selector switch to customize airflow (50-80-100 CFM).

KEY FEATURES:

Revolutionary ECM motor with SmartFlow™ technology for optimum CFM outputPick-A-Flow™ Speed Selector – one fan, you choose the CFM (50, 80 or 100 CFM)Optional built-in Multi-Speed Control for ASHRAE 62.2 complianceBuilt-in condensation sensor to control bathroom moistureLow profile 3-3/8” depth fits virtually anywhere, including 2×4 construction

SPECIFICATIONS:

Air Volume Exhaust (CFM) 50 @ 0.1″ SP, 52 @ 0.25″ SP, 80 @ 0.1″ SP, 81 @ 0.25″ SP, 100 @ 0.1″ SP, 101 @ 0.25″ SPMaster Carton Dimensions (HxWxD) 6.89 x 14.25 x 16.73CFM 50-70. 80-110Other Approved Codes and Standards ASHRAE 62.2, LEED, California Title 24, Washington VIAQConstruction Type Single-Family/Manufactured Housing. Multi-Family. Hospitality/Assisted Living/Student Housing. Renovation/Remodeling.Current (Amps) 50 CFM= .08A, 80 CFM= .13A, 100 CFM= .18AVentilation Design Approach Continuous Ventilation. Spot VentilationDuct Diameter 4″ OvalEnergy Efficiency (CFM/Watt) 50 CFM= 12.1 CFM/W, 80 CFM=10.0 CFM/W, 100 CFM = 8.2 CFM/WENERGY STAR® Certified YesFan Type Fan OnlyGrille Size (in sq.) 13″Industry Residential. Light CommercialInstallation Ceiling Mount, Wall Mount (UL), Tub/Shower (UL)Motor Type (AC/DC) ECMMounting Opening (in sq.) 10-1/2″Mounting Options Ceiling Mount. Wall Mount (UL). Tub/Shower (UL)Noise (Sones) 50 @ 0.1″ SP = < 0.3, 52 @ 0.25″ SP = 0.5, 80 @ 0.1″ SP = less than 0.4, 81 @ 0.25″ SP = 0.8, 100 @ 0.1″ SP = 0.9, 101 @ 0.25″ SP = 1.3Power Consumption (Watts) 50 CFM= 4.5W, 80 CFM= 8.5W, 100 CFM=12.4WPower Rating (V/Hz) 120/60Product Family Name WhisperValue DCRadiation Damper Available YesUL Listed for Tub/Shower Enclosure when GFCI Protected YesWarranty 6 year DC Motor, 3 Year PartsMaster Carton Gross Weight (lbs.) 9.0
