Nora Lighting NIO-4RTLA35XBB/10 4″ Iolite LED Round Trimless Adjustable, 1000lm / 14W, 3500K – Black Adjustable / Black Reflector

Description

4″ Trimless Iolite luminaires have no exposed trim flange and do not extend beyond the ceiling plane. Iolite Trimless requires a Trimless Mud Ring and New Construction housing. The Regressed cone reflector optimizes visual cut-off and adjusts up to 35°.

Color Temperatures: 3500K

Lumens / Wattage:

• 800lm / 14W (NHIOICD-48, NHIOICDCP-48)
• 1000lm / 14W (NHIOICD-48, NHIOICDCP-48)
• 1500lm / 20W (NHIOICD-415, NHIOICDCP-415)
• 2000lm / 24W (NHIOICD-420, NHIOICDCP-420)

Optics: Field Changeable (Spot, Narrow Flood, Flood) or 10° Narrow Spot

Required: Trimless Mud Plate (NIO-TLMR-4RA)

Additional information

Family	Iolite
Light Source	LED, Comfort Dim
Aperture Size	4″
Flange Type	Trimless
Application	Adjustable, Downlight
Construction Type	Chicago Plenum, New Construction, Air-Tight IC
Options	Title 24, ENERGY STAR certified

Download PDF File

Specification

Installation Instructions
