178 One Light Track Head in White (34|JTK-178-WT)

Description

WAC Limited One Light Track Head by W.A.C. Lighting from the 178 collection in White finishLine Voltage luminaires offer a large assortment of styles, finishes and features for residential, retail, commercial and hospitality environments. Ideal for applications where a minimalist profile is desired, achieve the sleek look of MR16 fixtures without the need for a bulky transformer. Track Fixture is available in H, J/J2, and L track configurations. Order according to track layout specifications. Fixture can accommodate an LED lamp. {ADDITIONAL FINISH INFORMATION: White}

Characteristics and Features

FAMILY: 178
STANDARD STYLE: CONTEMPORARY MODERN
IMAGE INFO: ACTUAL
LIGHT SOURCE: INCANDESCENT OR LED
MATERIAL: FORMED METAL TRACK HEAD WITH DIE-CAST LOCKING KNOB FOR AIMING AND POLYCARBONATE TRACK ADAPTER. MEDIUM BASE 250V PORCELAIN SOCKET WITH NICKEL-PLATED COPPER SCREW SHELL.
UL LISTED: UL CUL
UL RATING: UL CUL

Dimensions & Measurements

HEIGHT: 4.00
HEIGHT RANGE: 0-15”
WIDTH: 1.75
WIDTH RANGE: 0-15”
EXTENSION: 2.50

Electrical Specifications

NUMBER OF BULBS: 1
BULB TYPE: PAR20
BULB BASE: BR PAR20/30/38
VOLTAGE: 120.00
MAX WATTAGE: 75.00

Included Components

Warranty and Product Information

MANUFACTURER WARRANTY: 5 YEAR FUNCTIONAL 2 YEAR FINISH
PARTS DIAGRAM:
